Gleaming Novelties: ADT CLF-921 Water Control Circulation Systems

In Stock

ADT CLF-921 Water Control Circulation Systems

ADT CLF 921 Water Control Circulation Systems create an optimal emulsion for cooling the blade by constantly mixing, cooling, and filtering water used during the dicing process with a suitable additive. By utilizing a non-polluting, cost-effective process, CLF-921 circulates water and additives to stabilize process conditions.

System Highlights

  • Water circulation
  • Two-stage filtration
  • Accurate temperature control
  • Constant additive concentration level mechanism
  • Integration with two saws simultaneously
  • Safety and process control features:
  • Anti-freezing protection
  • Over-flowing alarm
  • Clogged filter indication
  • Low additive indication

Technical Specification

  • Water flow capacity: 14 l/min
  • Cooling capacity: 1600 W @ 20°C
  • Set point range: 5°C – 25°C
  • Temperature stability: +/-1°C
  • Filtration particle size: 25, 50, 100, 150, 200 μm
  • Dimensions: 1300 x 560 x 750 mm
  • Approx. machine weight (empty/full): 150/250 kg
  • Additive type: BPS-729B Air Products
